OK-M210

  • Model: OK-M210
  • Voltage: 220V 50/60Hz
  • Rotary Speed: 1-100 times/min
  • Outer Diameter of Quartz: 8-22mm
  • Dimensions - L*W*H (mm): 300*240*690mm
  • Weight: 45kgs

We're here to help:

Easy ways to get the answers you need.


  • quartz ampoule vacuum sealing system
Technical Parameters of  Oxyhydrogen Generator:
 Okay Energy Rotary Quartz Vacuum Sealing Device
Model OK-M210
Voltage 220V 50/60Hz
Name Rotary Quartz Vacuum Sealing Device
Number of Workstation 1 pcs
Dimension-L*W*H(mm) 300*240*690
Outer Diameter of Quartz Tube 8-45mm
Thickness of Tube Wall 2mm
Vacuum Joint KF25
Air Escape Valve KF16
Speeder
LCD screen
Optional Sealing Device Oxyhydrogen Generator,Vacuum Pump


Product Details:
 Quartz tube vacuum sealing machine is simple and easy to operate,which widely used in advanced materials research. There is unique rotary seal flange. So, it could adjust and display the sealing speed of tube casually and tube could be sealed without manual rotation, which could greatly improve the sealing efficiency of tube.

The device is made with high vacuum rotary seal system, high vacuum pipeline, intake port, suction port, vent valve and glass test tube flange. It is used for the vacuum sealing of daily high purity raw materials in university and lab of institution. It could be used in factory to have tube sealing, vacuum sealing of quartz glass tube and vacuum seal of borate glass. The isolation of samples of after-melting of quartz in the mouth of tube and outer air could have effective protection sample that is sensitive to air. Sample could be burned or transported in a long time as well as switching of suitcases after sealing. Quartz tube vacuum sealing machine could provide 1-2 workstaion and there could be customization for multiple machines.

When sealing quartz tube, it is necessary to equip with industrial oxyhydrogen generators to melt glass tube fastly.Generally speaking,we suggest you choose the oxyhydrogen generators based on the the external diameter and thickness of glass tube.

External Diameter of glass tube Thickness of glass tube wall Oxyhydrogen generator model
≤10mm ≤1mm OH400-OH600
≤16mm ≤1.5mm OH800-OH1000
≤25mm ≤2mm OH2000
≤35mm ≤3mm OH3000

How to seal quartz tube under vacuum?
Here sealing video opration about the whole set including oxyhydrogen generator OH1000 + quartz vacuum sealing system OK-M210 + vacuum pump
