HHO Torch for Fine Jewelry Gold & Platinum Welding

OH200 Jewelry Welding Machine

The oxyhydrogen generator provides a clean, precision heat source for gold and silver jewelry welding, suitable for precise fusion of fine wires, clasps and chains.

Model

OH200

AC Voltage Requirement(V)

220/110

Phase

single

Power Consumption(kw/h)

0.7

Max. Gas Output(L/h)

200

Max. Working Pressure(Mpa)

0.14

Description:

The oxyhydrogen generator provides a clean, precision heat source for gold and silver jewelry welding, suitable for precise fusion of fine wires, clasps, chains, and prong settings. The stable flame produces bright, fully-filled joints without the need for flux or risk of carbon black contamination. On-demand gas generation eliminates high-pressure storage risks, significantly improving bench-top safety and air quality.

Oxyhydrogen flame is ideal for jewelry studios, repair shops, and watch repair operations, our solution ensures aesthetic weld quality while lowering total operational costs.

Technical Parameters:

Model	OH200
AC Voltage Requirement(V)	220/110
Power Consumption(kw/h)	0.7
Max. Gas Output(L/h)	200
Max. Working Pressure(Mpa)	0.14
Max. Water Consumption(L/h)	0.11
Water Feed	manual
Flame Modifier Feed	manual
Dimensions-LWH (mm)	450246470
Weight(kg)	17
Ventilation Space Requirement(mm)	200 in each direction

Features:

1. High Flame Temperature for Gold & Platinum:
HHO flame reaches up to 3000°C, easily melting high-melting-point precious metals such as platinum and gold.
2. Fine and Controllable Flame:
Flame can be adjusted to pinpoint size, suitable for micro-solder joints, fine chain links, and complex structures.
3. Oxidation-Free Welding:
The hho flame has reducing properties, producing bright, scale-free solder joints, reducing polishing steps.
4. No Flux Required:
The reducing atmosphere of the hho flame eliminates the need for flux when welding precious metals, avoiding residual contamination.
5. No High-Pressure Cylinders, Safe & Reliable:
Gas is produced on demand, eliminating the need to store hydrogen or acetylene cylinders, removing safety hazards in the workspace.
