Details:
oxy hydrogen gas welding machine can work continuously and working life is 5-8 years. It is recommended for small factory and repair workshop.
Oxyhydrogen generator can electrolyze water into hydrogen gas and oxygen gas. We can use H2 and O2 as the fuel of flame replacing LPG, propane, acetylene fuel, natural gas or others. These gases are then mixed and applied in jewelry industry, such as jewelry wax casting,jewelry repair and welding. The oxy-hydrogen flame temperature is up to 2800℃. It can polish the acrylic sheet rapidly.
-
Technical Parameters:
|
Model Number
|
SOH100
|
|
Type
|
conventional type
|
|
AC Voltage Requirement(V)
|
220/110
|
|
Phase
|
single
|
|
Power Consumption(kw/h)
|
0.35
|
|
Max. Gas Output(L/h)
|
100(adjustable)
|
|
Max. Working Pressure(Mpa)
|
0.14
|
|
Max. Water Consumption(L/h)
|
0.06
|
|
Water Feed
|
manual
|
|
Flame Modifier Feed
|
manual
|
|
Dimensions-L*W*H (mm)
|
390*250*510
|
|
Gross Weight(kg)
|
11
|
|
Ventilation Space Requirement(mm)
|
200 in each direction
|
Advantage characteristics:
1.Easy and safety operation
It produce oxy-hydrogen gas by automatic way as you required. Machine will shut down automatically when the gas pressure is too high
2.Welding fast
The oxy-hydrogen flame temperature is high up to 2800 degree, it can heat the welding spot to melting point fast in about 1 second to finish welding.
3.Welding precisely The flame is concentrated, it can achieves welding of precise devices.
4.Smooth welding spot
Oxy-hydrogen flame combustion doesn't form carbide, so there is no black spot, avoid the second treatment of cleaning and polishing.
5.Environment friendly
Oxyhydrogen welding machine 's fuel comes from water.
There is water vapor after combustion.No harm to environment.
6. Energy saving
oxyhydrogen generator saves energy cost over 30% compared with other gas welding way.Adding the oxygen cost, it will save cost over 40%.
